Aluminum Coil

Aluminum coil can be produced from aluminum ingots or other forms of raw aluminum (called cold rolling or direct cast) or from a smelting process directly through rolling (called continuous cast). These sheets of rolled aluminum are then rolled up, or coiled, around a core. These coils are densely packed, making them easier to ship and store when compared to aluminum in sheet form.

Inquiry Form

Product Parameters

Material
1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc.
2000 Series: 2014, 2024, etc.
3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc.
4000 Series: 4045, 4047, 4343, etc.
5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5454, 5754, 5A06, etc.
6000 Series: 6061, 6063, 6082, 6A02, etc.
7000 Series:7075,7475
Standard
AISI,ASTM,DIN,JIS,GB,GOST, ect.
Surface Treatment
Coated, Embossed,Brushed, polished, Anodized,etc.
Processing Service
Bending,Welding,Decoiling,Cutting,Punching
Size Tolerance
Thickness error:±0.005mm Width error:0.1mm
Certificate
ISO9001 ,CE, SGS,etc.
Application
Construction filed, Ships building industry, Decoration, Industry,Manufacture,Machinery and hardware fields, etc

Chemical composition

Grade
Si
Fe
Cu
Mn
Mg
Zn
Ti
Other
AI
1050
0.25
0.4
0.05
0.05
0.05
0.05
0.03
0.03
99.5
1060
0.25
0.35
0.05
0.03
0.03
0.05
0.03
0.03
99.6
1100
0.95
0.95
0.05-0.2
0.05
–
0.1
–
0.15
99
2A12
0.5
0.5
3.8-4.9
0.3-0.9
1.2-1.8
0.3
0.15
1.0
Remains
2017
0.2-0.8
0.7
3.5-4.5
0.4-1.0
0.4-0.8
0.25
0.15
0.15
Remains
2014
0.5-1.2
0.7
3.9-5
0.4-1.2
0.2-0.8
0.25
0.15
0.15
Remains
3003
0.6
0.7
0.05-0.2
1.0-1.5
–
0.1
–
0.15
Remains
3005
0.6
0.7
0.3
1.0-1.5
0.2-0.6
0.25
0.1
0.15
Remains
3105
0.6
0.7
0.3
0.3-0.8
0.2-0.8
0.4
0.1
0.15
Remains
5005
0.3
0.7
0.2
0.2
0.5-1.1
0.25
–
0.15
Remains
5052
0.25
0.4
0.1
0.1
2.2-2.8
0.1
–
0.15
Remains
5083
0.4
0.4
0.1
0.4-1.0
4.0-4.9
0.25
0.15
0.15
Remains
5182
0.2
0.35
0.15
0.2-0.5
4.0-5.0
0.25
0.15
0.15
Remains
5754
0.4
0.4
0.1
0.5
2.6-3.6
0.2
0.15
0.15
Remains
6061
0.4-0.8
0.7
0.15-0.4
0.15
0.8-1.2
0.25
0.15
0.15
Remains
6063
0.2-0.6
0.35
0.1
0.1
0.45-0.9
0.1
0.1
0.15
Remains
6082
0.7-1.3
0.5
0.1
0.4-1
0.6-1.2
0.2
0.1
0.15
Remains
7075
0.4
0.5
1.2-2.0
0.3
2.1-2.9
5.1-5.6
0.2
0.15
Remains

Aluminum coil classification

1000 series
The 1000 series aluminum plate is also called pure aluminum plate. Among all the series, the 1000 series has the highest aluminum content. The purity can reach more than 99.00%. Since it does not contain other technical elements, the production process is relatively simple and the price is relatively cheap. It is the most commonly used series in the conventional industry. Most of the 1050 and 1060 series are in circulation on the market. The 1000 series aluminum plate determines the minimum aluminum content of this series based on the last two Arabic numerals. For example, the last two Arabic numerals of the 1050 series are 50. According to the international brand naming principle, the aluminum content must reach more than 99.5% to be a qualified product. my country’s aluminum alloy technical standard (gB/T3880-2006) also clearly stipulates that the aluminum content of 1050 reaches 99.5%. For the same reason, the aluminum content of 1060 series aluminum plates must reach more than 99.6%.

2000 series aluminum plate
Representative 2A16 (LY16) 2A06 (LY6) 2000 series aluminum plate is characterized by high hardness, with the highest copper content, about 3-5%. 2000 series aluminum plate belongs to aviation aluminum and is not often used in conventional industries. There are few manufacturers in my country that produce 2000 series aluminum plates. The quality cannot be compared with that of foreign countries. Imported aluminum plates are mainly provided by Korean and German manufacturers. With the development of my country’s aerospace industry, the production technology of 2000 series aluminum plates will be further improved.

3000 series aluminum plate
Represented by 3003 3003 3A21. Also known as rust-proof aluminum plate. my country’s 3000 series aluminum plate production process is relatively excellent. 3000 series aluminum plate is mainly composed of manganese elements. The content is between 1.0-1.5. It is a series with good rust-proof function. It is generally used in humid environments such as air conditioners, refrigerators, and car bottoms. The price is higher than the 1000 series. It is a more commonly used alloy series.

4000 series aluminum plate
Represented by 4A01 4000 series aluminum plate belongs to the series with high silicon content. Usually the silicon content is between 4.5-6.0%. It is used as building materials, mechanical parts, forging materials, welding materials; low melting point, good corrosion resistance Product description: It has the characteristics of heat resistance and wear resistance

5000 series
Represents 5052.5005.5083.5A05 series. 5000 series aluminum plate belongs to the more commonly used alloy aluminum plate series, the main element is magnesium, and the magnesium content is between 3-5%. It can also be called aluminum-magnesium alloy. The main characteristics are low density, high tensile strength and high elongation. The weight of aluminum-magnesium alloy is lower than other series under the same area. Therefore, it is often used in aviation, such as aircraft fuel tanks. It is also widely used in conventional industries. The processing technology is continuous casting and rolling. It belongs to the hot-rolled aluminum plate series, so it can be oxidized and deep processed. In my country, 5000 series aluminum plate is one of the more mature aluminum plate series.

6000 Series
Represents 6061 Mainly contains two elements, magnesium and silicon, so it concentrates the advantages of 4000 series and 5000 series. 6061 is a cold-treated aluminum forging product, suitable for applications with high requirements for corrosion resistance and oxidation resistance. Good workability, excellent interface characteristics, easy coating, and good processability. It can be used in low-pressure weapons and aircraft joints.
General characteristics of 6061: excellent interface characteristics, easy coating, high strength, good workability, and strong corrosion resistance.
Typical uses of 6061 aluminum: aircraft parts, camera parts, couplers, ship accessories and hardware, electronic accessories and joints, decorative or various hardware, hinge heads, magnetic heads, brake pistons, hydraulic pistons, electrical accessories, valves and valve parts.


7000 series
Represents 7075, which mainly contains zinc. It also belongs to the aviation series. It is an aluminum-magnesium-zinc-copper alloy, a heat-treatable alloy, and a super-hard aluminum alloy with good wear resistance. The 7075 aluminum plate is stress-eliminated and will not deform or warp after processing. All super-large and super-thick 7075 aluminum plates are ultrasonically detected to ensure that there are no sand holes or impurities. The 7075 aluminum plate has high thermal conductivity, which can shorten the molding time and improve work efficiency. The main feature is high hardness. 7075 is a high-hardness, high-strength aluminum alloy, which is often used in the manufacture of aircraft structures and futures. It requires high-strength, high-corrosion resistance, high-stress structural parts and mold manufacturing. It basically relies on imports, and my country’s production technology needs to be improved. (The company once had a foreign company propose that the domestically produced 7075 aluminum plate was unevenly annealed, and the surface and internal hardness of the aluminum plate were inconsistent)

The most commonly used aluminum sheet in the 8000 series is 8011, which belongs to other series. As far as I remember, it is mainly used to make bottle caps, and is also used in radiators, mostly in aluminum foil. It is not commonly used. The 9000 series belongs to the backup series. With the development of technology, in order to cope with the emergence of aluminum sheets containing other alloy elements, the International Aluminum Sheet and Strip Federation specifically stated that the 9000 series is a backup series, waiting for another new variety to appear to fill the gap in the 9000 series.
